| Model No. | ATT2-XX-6-SMBMF(XX means attenuation in dB) | ||||||||||||||||
| Attenuation(dB) | 3 | 5 | 6 | 7 | 8 | 10 | 13 | 15 | 20 | 30 | |||||||
| Accuracy(dB) | ±0.5 | ±0.5 | ±0.8 | ±0.8 | ±0.8 | ±1.0 | ±1.2 | ±1.2 | ±1.2 | ±1.5 | Wide Frequency Band Covering DC-4GHz | ||||||
| Freq(MHz) | DC-6GHz | Good Performance in Attenuation Accuracy | |||||||||||||||
| VSWR | ≤1.25 | Indoor Using IP60 | |||||||||||||||
| Power Rating(W) | 2W (average) | Low VSWR | |||||||||||||||
| Impedance | 50 ohm | Available with Type N, 7/16DIN or 4.3/10 Connectors | |||||||||||||||
| Connector | SMB Male to SMB Female | ||||||||||||||||
| Material | Brass | ||||||||||||||||
| Operating Tem(℃) | -55°C to +125°C | ||||||||||||||||
| Weight(kg) | 0.01 | ||||||||||||||||
